MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire

MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire

제품 상세 정보:
원래 장소: 중국
브랜드 이름: Mettler Toledo
모델 번호: 로드 셀 MT1041-75kg 6m
결제 및 배송 조건:
최소 주문 수량: 1 세트
가격: 협상 가능
포장 세부 사항: 카론 박스
배달 시간: 10-30days
공급 능력: 달 당 2000 세트
접촉
상세 제품 설명
제품: 메틀러 톨레도 로드 셀 최대 용량: 196 파운드 (75kg)
소재: 알루미늄, 수로 도량형학: NTEP III 5,000D OIML C3
정확성: 기준 보호 등급: IP67
플랫폼 크기 (LXW): 400 mm x 400 mm 연결성: 아날로그
케이블: 20 피트 (6m)
강조하다:

MT1041 75kg load cell

,

robust weight sensor with wire

,

Mettler Toledo load cell sensor

MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire
A compression weigh module designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing.
Product Attributes
Attribute Value
Product Mettler Toledo Load Cell
Maximum Capacity 196 lb (75 kg)
Material Aluminum, passivated
Metrology NTEP III 5,000d OIML C3
Accuracy Standard
Protection Rating IP67
Platform Size (LxW) 400 mm x 400 mm
Connectivity Analog
Cable 20 ft (6 m)
Key Features
For Mid Size Platforms
The MT1041 is a high performance single point load cell. The load cell is off-center compensated, enabling it to cope with platform moments. Metrology approvals include OIML as standard.
Reliable Strain Gage Technology
Usage of premium aluminum materials and strain gage technology guarantees long-term durability.
Hazardous Area Usage
ATEX Zone 1/21/2/22 approvals as standard. No need to ask for options or stock variations - one fits all applications.
Technical Specifications
Material: Aluminum, passivated
Material No: 72208504
Maximum Capacity: 196 lb (75 kg)
Protection Rating: IP67
Connectivity: Analog
Cable: PVC, 20 ft (6 m)
Platform Size (LxW): 400 mm x 400 mm
Accuracy: Standard
Metrology: NTEP III 5,000d, OIML C3
MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire 0
